15mm Animal Feed Milling Pellet Production Plant 100KW 4T/H

Product Categories
Henan Strongwin Machinery Equipment Co., Ltd.
Contact Now

15mm Animal Feed Milling Pellet Production Plant 100KW 4T/H

  • 1
  • 2

Brand Name : Strongwin

Model Number : SZLH320

Certification : CE,ISO,SGS

Place of Origin : China

MOQ : one set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 200 sets per year

Delivery Time : 15-30 working days after deposit

Packaging Details : Wooden Case or In Container

Machine name : Manufacture Animal Feed Milling Plant With Steel Structure And Silos

Power : 100KW

Final pellet : 2-15mm

Capacity : 2-4T/H

Application : Animal Feed

Service : With Engineers design and installation

Contact Now

Manufacture Animal Feed Milling Plant With Steel Structure And Silos



Strongwin factory supply 1-30T/H animal feed milling plant for Customers.



Features of animal feed milling plant


1. Can process many kinds of raw materials into feed pellets.
2. Automatic PLC control system for the whole feed plant.
3. Environment-friendly production with no any waste water and exhaust gas during the production process.
4. Widely applied many poultry animal feeds, Set Up Feed factory. Kind of Farms.


Technical Parameters of animal feed milling plant

Item Name Type Qty Power (KW)
Part 1. Raw material receiving& crushing system
1 Grass crusher FSP500B-22 1 22
1-103 Impulse Filter TBGM20 1
1-105 Bucket Elevator TDTG36/23 1 4
1-106 Cylinder Filtering Sieve TCQY63 1 0.75
1-107 Additive Blender TCXT20 1
1-110 Impeller speed regulating Feeder SWLY60 1 1.1
1-111 Crusher SFSP66*60 1 55
1-114 Impulse Filter TBLMa24 1
1-116 Wind-shielding Screw conveyor TLSB20 1 2.2
Part 2. Mixing System
2-202 Bucket Elevator TDTG36/23 1 4
2-203 Powder Screener SCQZ60 1 5.5
2-207 Feeder for additive   1
2-208 Mixer SLHS1.0 1 11
2-210 Scraper Conveyor TGSU20 1 3
Part 3. pelleting system
3-308 Pellet Mill SZLH350 1 57.95
3-310 Cooler SKLN3 1 1.5
Part 4. Packing system
4-401 Bucket elevator TDTG36/18 1 3
4-402 Rotary Screener SFJH80*2d 1 2.2
4-409 Auto Packing Scale 10-50KG 1 1.5
4-410 Stitch conveyor   1 1.5
Part 5. Auxiliary Equipment System
5-506 Steam Supplying System   1
5-507 Oil adding System   1 2.2
5-508 Oil Adding Tube   1
5-509 Calabash Crane   1 3



15mm Animal Feed Milling Pellet Production Plant 100KW 4T/H15mm Animal Feed Milling Pellet Production Plant 100KW 4T/H
